Business productivity and efficiency is the irresistible force driving Enterprise to adopt mobile tools. The SyntegraTech PA962 was specifically designed to increase your productivity in the warehouse, on the road, or in the field - by dynamically linking data collection and host systems wirelessly.

The PA962 incorporates a built-in scanner for industry standard bar codes, a 19 key keypad, and a touch screen. Data Collection is simple, fast and accurate. Expansion slots for WLAN or WWAN makes real world data transaction possible where you really need it - in the field.
Working environments are not always perfectly lit, so the PA962 features an LCD and keypad backlight that makes anytime, anywhere operation possible. Control the keypad backlight on/off and LCD backlight contrast for power saving via a simple hot key.

The rugged PA962 can withstand 1.2 meter (4 foot) bounces off a concrete floor and is sealed to IP54 standards against water and dust. The rugged housing protects the terminal against the harsh working environment often encountered by mobile users. The double-cell battery pack provides long hours of mobile operation, uncompromised productivity, and minimal down time.

The PA962 comes equipped with both a PCMCIA Type II slot and a CF Type I/Type II slot for WWAN, WWLAN, memory, and many other uses. The PA962 communicates with a host system via USB, RS232, Bluetooth, and IrDA, or take advantage of the PA966’s built-in PCMCIA slot for WiFi and other communication options.

Despite IP54 sealing and the double-cell battery, the PA962's ergonomic design still easily fits the user's hand. Users increase productivity right from the start with minimum training thanks to the PA962's vivid 240 by 320 color display, touch screen, and the familiar Windows operating system.

INTERNAL PERFORMANCE Operating System Microsoft Windows CE 5.0 Professional Plus CPU 400Mhz Intel PXA255 Processor Memory 64 MB SDRAM / 64 MB Flash ROM

EXTERNAL CHARACTERISTICS Dimensions 7.89”H x 3.49”W x 1.79”D Weight 15.5 ounces Display 3.5” color QVGA (240 x 320 pixels) Backlit touch-screen, transflective TFT-LCD Keypad 19-key alphanumeric keypad, Backlit (includes function and cursor keys) Indicator LED (green/red) Audio beeper

COMMUNICATION Batch USB 1.1 RS232C Wireless Bluetooth (Class II) WLAN WWAN (GSM / GPRS / EDGE / 2.5G) IrDA SIR 1.2 – 115 to 200 baud rate 802.11 b/g Security WEP, WPA, APA2-TKIP, AES Passkey (Bluetooth)

BATTERY and POWER Main Battery 7.4V Li-Ion 1850mAh rechargeable battery pack Battery Life 8-hours to 10-hours (configuration-dependant) Extended Battery 1.2V Ni-MH 600mAh rechargeable battery Charging Time 3-hours with the charging cable or the docking station Docking Station USB, RS232 cradle with spare battery charging function Power Input 12V AC adapter

CONNECTION & EXPANSION Slots PCMCIA type II CF type I/II Ports RS232C Infrared

FIELD ENVIRONMENT Drop Threshold 4’ Environmental Sealing IP54: Completely sealed against dust and splashes Humidity 5% to 95% (non-condensing) Operating Temperature 23ºF to 122ºF (-5ºC to 50ºC) Storage Temperature -4ºF to 140ºF (-20ºC to 60ºC)

INPUT DEVICES Laser Bar Code Scanner Light source 650 ± 10 nm visible laser diode Scan rate 39 ± 3 scans/sec. Contrast 25% absolute dark/light reflectance Scan angle 53º nominal Depth of field 5.0 mils: 2 - 5.2" (51 - 132mm) 7.5 mils: 1.7 - .8" (43 - 203mm) 10.0 mils: 1.8 - 10" (46 - 254mm) 15.0 mils: 1.9 - 13" (48 - 330mm) 20.0 mils: * - 20" (* - 508mm) 40.0 mils: * - 25" (* - 635mm) 55.0 mils: * - 30" (* - 762mm) * - depending on symbol width Symbologies Codabar Code 11 Code 32 Code 39 Full ASCI Code 39 Standard Code 93 Code 128 Delta Code EAN-8 (add-on 2/5) EAN-13 (add-on 2/5) EAN 128 Interleaved 2 of 5 ISBT 128 MSI/Plessey Standard 2 of 5 Toshiba Code UPC-A (add-on 2/5) UPC-E (add-on 2/5) RFID Reader (Via PCMCIA Slot) Frequency 13 to 56 MHZ Supporting Tags ISO 15693, Tag it, I-Code, I-Code SLI Reading Distance Terminal level about 1.18” to 2.75”

IN the BOX PA962 Power Supply Battery USB cable Manuals Quick Start Guide
